- Dual channel DDR4-2666 SODIMMs, 1.2V, 64GB maximum
|
- 2 22x42/80 key M slot for PCIe x4 Gen3 NVMe/ AHCI or SATA3 SSD
|
- Intel Optane Memory M10 and H10 ready
|
- HDMI 2.0a port and DisplayPort 1.2 via Thunderbolt 3/USB-C port
|
|
- Intel i219-V 10/100/1000 Mbps Ethernet
|
- Intel Wifi 6 AX200 2x2 160MHz channels + Bluetooth v5, internal antennas
|
- Front USB 3.1 Gen2 Type C (5V/9V fast phone charging profiles) and type-A ports
|
- 2x rear USB 3.1 Gen 2 and 2x internal USB 2.0 via header
|
- Front Consumer Infrared port
|
- SDXC slot with UHS-II support
|
- Up to 7.1 multichannel digital audio via HDMI or DisplayPort signals
|
- 5mm front stereo, headset jack
|
- Beam-forming, far-field, quad-mic array
|
- Plastic with metal inner frame, replaceable lid, Kensington lock with base security
|
- “Tall” H chassis: 117 x 112 x 51 mm, w/ 2.5’’ 7mm SATA3 bay and port
|
- “Slim” K chassis: 117 x 112 x 38 mm
|
- 12 – 19 Vdc input range, 19Vdc120W (Core i7 only) or 90W power supply with geo-specific C5 AC cords
|
- Front Panel, CEC, RGB LED, 2x USB2.0 headers
|
- Front panel status RGB LED
|
- Microsoft Window 10 logo’d, compatible with various Linux distros
|
- VESA mounting plate included in kit SKUs only
|
- Individual retail packaging
|
|
