* THÔNG SỐ KỸ THUẬT
| Cooler Specification |
Socket compatibility AMD sTRX4, TR4, SP3 |
Height (without fan) 165 mm |
Width (without fan) 150 mm |
Depth (without fan) 52 mm |
Weight (without fan) 865 g |
Height (with fan) 165 mm |
Width (with fan) 150 mm |
Depth (with fan) 78 mm |
Weight (with fan) 1030 g |
Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
Max. TDP see CPU compatibility list |
Fan compatibility 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 |
Scope of delivery
|
Warranty 6 Years |
| FAN Specification |
Model Noctua NF-A15 PWM |
Bearing SSO2 |
Max. rotational speed (+/- 10%) 1500 RPM |
Max. rotational speed with L.N.A. (+/- 10%) 1200 RPM |
Min. rotational speed (PWM, +/-20%) 300 RPM |
Max. airflow 140,2 m³/h |
Max. airflow with L.N.A. 115,5 m³/h |
Max. acoustical noise 24,6 dB(A) |
Max. acoustical noise with L.N.A. 19,2 dB(A) |
Input power 1,56 W |
Voltage range 12 V |
MTTF > 150.000 h |
