* THÔNG SỐ KỸ THUẬT
Model | CS-CV228-A0-3C2WFR |
Image Sensor | 1/2.7inch Progressive Scan CMOS |
Shutter Speed | Self-adaptive shutter |
Lens | 2.8mm, view angle: 103° horizontal, 118° diagonal 4mm, view angle: 87° horizontal, 104° diagonal |
Lens Mount | M12 |
Day & Night | IR-cut filter with auto-switching |
DNR | 3D DNR |
WDR | Digital WDR |
Compression | |
Video Compression | H.265 / H.264 |
Video Bit Rate | Ultra-HD; HD; Standard. Adaptive bit rate |
Image | |
Max. Resolution | 1920 × 1080 |
Frame Rate | Max: 30fps; Self-adaptive during network transmission |
Network | |
Smart Alarm | Motion detection; Active sound and light alarm |
User Defined Alarm Tones | Supports |
Wi-Fi Pairing | AP Pairing |
Protocol | EZVIZ Cloud Proprietary Protocol |
Interface Protocol | EZVIZ Cloud Proprietary Protocol |
Interface | |
Storage | MicroSD card slot (Max. 256 GB) |
Wired Network | RJ45 × 1 (10M/100M Adaptive Ethernet Port) |
Wi-Fi | |
Standard | IEEE802.11 b/g/n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth | Supports 20MHz |
Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 144Mbps |
General | |
Power Supply | DC 12V/1A |
Power Consumption | 6W max |
IR Range | Max. 30m (98.43 ft.) |
IP Grade | IP67 |
Dimensions | Max Diameter: 105 mm (4.13inch); Height: 95 mm (3.74inch) |
Packaging Dimensions | 147mm x 145mm x 173mm (5.79inch x 5.71inch x 6.81inch) |
Bare Weight | 330g (0.73 lb) |
