THÔNG SỐ KỸ THUẬT
| Sản Phẩm | Cpu - Bộ vi xử lý |
| Hãng sản xuất | Intel |
| Model | E5-2696 v2 |
| Dòng CPU | Ivy Bridge-EP |
| Tốc độ | Frequency: 2.5 GHz Turbo Speed: 3.3 GHz |
| Nhân CPU | 12 |
| Luồng CPU | 24 |
| Bộ nhớ đệm | Level 1 cache size: 12 x 32 KB 8-way set associative instruction caches |
| Level 2 cache size: 12 x 256 KB 8-way set associative caches | |
| Level 3 cache size: 30 MB 20-way set associative shared cache | |
| Socket | FCLGA2011 |
| Bus Ram hỗ trợ | DDR3 800/1066/1333/1600/1866 |
| Dung lượng bộ nhớ tối đa (tùy vào loại bộ nhớ) | 768 GB |
| Số Kênh Bộ Nhớ Tối Đa | 4 |
| Hỗ trợ bộ nhớ ECC | Có |
| Xử lý đồ họa tích hợp | Không có |
| PCI Express | 3.0 (40 lines) |
| Dây truyền công nghệ | 22 nm |
| Tập lệnh hỗ trợ | MMX instructions SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions F16C / 16-bit Floating-Point conversion instructions EM64T / Extended Memory 64 technology / Intel 64 NX / XD / Execute disable bit HT / Hyper-Threading technology VT-x / Virtualization technology VT-d / Virtualization for directed I/O TBT 2.0 / Turbo Boost technology 2.0 TXT / Trusted Execution technology |
| TDP | 120W |
